Product Details
Place of Origin: Changsha, Hunan, China
Brand Name: Ibeno
Certification: ISO9001-2015
Model Number: Alumina Ceramics
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Packed in wooden cases or iron racks
Delivery Time: 25-45 workdas
Payment Terms: T/T
Supply Ability: 100,000 ㎡/ year
Material: |
Aluminum Oxide |
Thermal Expansion Coefficient: |
8.0 X 10^-6 /K |
Surface Finish: |
Polished |
Volume Resistivity: |
10^14 Ω·cm |
Chemical Resistance: |
Excellent |
Color: |
White |
Electrical Resistivity: |
10^14 Ohm-cm |
Other Name: |
Abrasion Resistant Ceramic |
Hardness: |
9 Mohs |
Tensile Strength: |
300 MPa |
Maximum Operating Temperature: |
1600°C |
Mechanical Strength: |
High |
Material: |
Aluminum Oxide |
Thermal Expansion Coefficient: |
8.0 X 10^-6 /K |
Surface Finish: |
Polished |
Volume Resistivity: |
10^14 Ω·cm |
Chemical Resistance: |
Excellent |
Color: |
White |
Electrical Resistivity: |
10^14 Ohm-cm |
Other Name: |
Abrasion Resistant Ceramic |
Hardness: |
9 Mohs |
Tensile Strength: |
300 MPa |
Maximum Operating Temperature: |
1600°C |
Mechanical Strength: |
High |
Product Description
High-quality wear-resistant ceramics are special corundums made of Al₂O₃ as the main raw material, rare metal oxides as the flux, and fired at a high temperature of 1700°C.
We produce high-quality wear resistant ceramics, the main types are 99% bulletproof ceramics, diamond-shaped ceramics, special-shaped ceramic blocks, wear-resistant ceramic blocks with grooves, trapezoidal ceramics, diamond-shaped ceramics, cylindrical ceramic rings, L-shaped ceramics, etc., all models can be customized according to customer requirements.
Alumina Bulletproof Ceramic Sheet: Alumina ceramic material is an important part of bulletproof materials. It has high hardness and wear resistance, high compressive strength, and excellent ballistic performance under high stress.
Technical indicators
Technical parameters: Alumina content ≥99%, density ≥3.88g/cm3, hardness>1500 (HV5), flexural strength>350MPA, impact toughness ≥2.2J/cm², elastic modulus>320GPA.
Product Features
With good wear resistance and impact resistance, the use of high quality wear resistant ceramics can help customers extend the service life of the equipment and reduce unnecessary maintenance costs.
99% alumina ballistic ceramic sheet has high hardness and wear resistance, high compressive strength, and excellent ballistic performance under high stress. It has high mechanical properties, especially fracture toughness, and resists the firing of bullets. Alumina ceramics are very suitable as bulletproof ceramics.
Technical parameters
| Items | Specifications | |
| Content of alumina | ≥92% | ≥95% |
| Density | ≥3.6 g/cm3 | >3.8g/cm3 |
| Rockwell A hardness | ≥82HRA | ≥85HRA |
| Impact strength | ≥1200 MPA | ≥1500 MPA |
| Fracture toughness | ≥3.8MPa·m1/2 | ≥4.0MPa·m1/2 |
| Vickers hardness | ≥1150HV10 | ≥1200HV10 |
| Bending Strength | ≥290MPa | ≥330MPa |
Product Specifications
The size of the ceramic patch is 150×150, 300×300, 500x500mm, etc. (the alumina ceramic sheet is selected by the customer according to the actual needs)
Hexagonal mosaic size: 12mmx3mm, 12mmx6mm, 12mmx12mm, etc.
Square mosaic size (L*W*H): 10x10x2mm, 10x10x3mm, 10x10x4mm, 10x10x8mm, 17.5x17.5x10mm, 20x20x4mm, 20x20x5mm, 20x20x6mm, 20x20x8mm, 20x20x10mm, etc.
Rectangular mosaic size (L*W*H): 15x30x3mm, 30x60x6mm, etc.
The material behind the patch: self-adhesive, acetate cloth, transparent glue, nylon mesh, etc. (Thousands of specifications can be customized)
Company Profile
Yibeinuo New Material is a national high-tech manufacturing enterprise integrating R&D, design, manufacturing, and technical services in domestic wear-resistant ceramics. It has a certain influence on the domestic wear-resistant industry. Its products are widely used in steel, cement, coal, and ports. , Chemical, lithium battery, mineral processing, construction machinery, and other industries, are exported to Southeast Asia, South Korea, Japan, Australia, Europe, the United States, and other countries, and are well received by users at home and abroad!
What are High-Quality Wear Resistant Ceramics?
High Quality Wear Resistant Ceramics are a type of advanced ceramic that’s specifically designed for tough, harsh environments. Unlike traditional ceramics, High Quality Wear Resistant Ceramics are engineered to withstand high temperatures, corrosion, and abrasion while retaining their structural integrity. These ceramics can be used in a wide range of industries, including mining, cement, power generation, steel, and other heavy industries where equipment is exposed to extreme wear and tear.
Our Advantage
1. The factory is a manufacturing enterprise, dedicated to the production, design, research, and development of wear-resistant ceramics for 15 years
2. Years of practical experience in the industry can provide the best anti-wear design scheme for enterprise equipment
3. The perfect after-sales service system makes customers worry-free
4. The manufacturing process conforms to the ISO9001 standard.
5. We can provide free samples for customers and deliver them within 24 hours
6. Fast delivery time is 25-30 days
7. Provide OEM and buyer labeling services.
8. Provide high quality, competitive price, excellent service, and wear-resistant ceramic technology solutions.
