Home > products > Ceramic Sleeve Lined Pipe > Abrasion Resistant Ceramic Sleeve Lined Pipe Elbows Lithium Battery Wear-Resistant Ceramic Tubes

Abrasion Resistant Ceramic Sleeve Lined Pipe Elbows Lithium Battery Wear-Resistant Ceramic Tubes

Product Details

Place of Origin: Changsha, Hunan, China

Brand Name: Ibeno

Certification: ISO9001-2015

Model Number: Ceramic Sleeve Lined Pipe

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Packed in wooden cases or iron racks

Delivery Time: 25-45 workdas

Payment Terms: T/T

Supply Ability: 100,000 ㎡/ year

Get Best Price
Highlight:

Abrasion Resistant Ceramic Sleeve Lined Pipe

,

Abrasion Resistant Ceramic Lined Pipe Elbows

,

Cutting Ceramic Lined Pipe Elbows

Connection Type:
Flange/Socket Welding
Density:
3.65g/cm³
Hardness:
HRA 85-90
Inner Diameter:
10mm-1000mm
Installation Method:
Welding/Flange Connection
Lining Material:
Alumina Ceramic
Outer Diameter:
20mm-1200mm
Outer Material:
Steel
Pipe Diameter:
50-1200mm
Pipe Type:
Lined Pipe
Size:
1 Inch - 24 Inch
Sleeve:
Lined
Connection Type:
Flange/Socket Welding
Density:
3.65g/cm³
Hardness:
HRA 85-90
Inner Diameter:
10mm-1000mm
Installation Method:
Welding/Flange Connection
Lining Material:
Alumina Ceramic
Outer Diameter:
20mm-1200mm
Outer Material:
Steel
Pipe Diameter:
50-1200mm
Pipe Type:
Lined Pipe
Size:
1 Inch - 24 Inch
Sleeve:
Lined
Abrasion Resistant Ceramic Sleeve Lined Pipe Elbows Lithium Battery Wear-Resistant Ceramic Tubes

Product Description

Lithium battery wear-resistant ceramic tubes have alumina content of 92%, 95%, and 99%, which are made through sintering and precision machining processes. Ceramics have excellent wear resistance, corrosion resistance, high hardness, higher smoothness than metal materials, and easy installation.

Lithium Battery Wear Resistant Ceramic TubeAbrasion Resistant Ceramic Lined Pipe Elbow For Lithium BatteryWear resistant ceramic lined elbow used in Lithium Battery



Product parameters

Items Specifications
Al2O3 ≥95% ≥ 99%
Density >3.8g/cm3 >3.83g/cm3
HV10 ≥1200 ≥1300
Rock Hardness HRA ≥85 ≥90
Bending Strength MPa ≥330 ≥340
Compression strength MPa ≥1200 ≥1300
Fracture Toughness KIc MPam 1/2 ≥4.0 ≥4.2
Volume wear ≤0.02cm3 ≤0.01cm3

Factory introduction

The company's products have high strength, high hardness, wear resistance, and corrosion resistance. The products are exported to Japan, South Korea, Germany, the United States, the United Kingdom, Australia and other countries. The products are divided into the following series

1. Wear resistant ceramic sheet

2. Wear resistant ceramic liner

3. Wear-resistant ceramic composite pipelining

4. Lithium battery wear-resistant ceramic tube

5. Ceramic bushing tee

6. Wear resistant ceramic roller encapsulation

7. The overall equipment is lined with ceramics

8. Accessories on construction machinery ceramic pump tube, ceramic transition sleeve



Our Advantages

1. The manufacturing process complies with the ISO9001 standard.

2. We can provide customers with free samples and deliver them within 24 hours

3. The fast delivery time is 25-30 days

4. Provide OEM and buyer-label service.

5. High quality, competitive price, excellent service

6. Lithium battery wear-resistant ceramic tubes can be customized according to customer needs.



Product certification and product testing model

The company strictly controls each process of product production. We will have a series of testing equipment to conduct quality inspections to ensure that each factory product is 100% qualified.



Testing equipment includes:

Testing equipment Testing purpose
Rockwell hardness tester measuring the hardness of ceramics
Sandblasting testing machine measuring ceramic abrasion
Universal material testing machine measuring the compressive strength of ceramics
Microscope Porosity Analysis of Ceramic Surface
Universal material testing machine measuring the compressive strength of ceramics
Tensile testing machine Tensile testing
Density meter ceramic density analyzer
Impact testing machine ceramic compressive strength test

Why is the wear-resistant ceramic pipe popular for lithium batteries?

The use of lithium batteries has become prevalent in recent years with the development of various electronic devices, tools, and appliances. As a result, the demand for lithium battery cathode material pipelines is increasing constantly. The pipeline is responsible for transporting the lithium battery cathode material that powers devices, and it is a critical part of the lithium battery cell manufacturing process.

In the past, there were only two types of cathode material pipelines used in the lithium battery industry: metal pipelines and glass pipelines. However, in recent years, wear-resistant ceramic lithium battery pipelines have become increasingly popular. The reason for this is that these ceramic pipes offer several unique benefits over their metal and glass counterparts.



One of the biggest advantages of using wear-resistant ceramic pipelines is their significant improvement in durability and wear resistance. These pipes are made from advanced materials that allow them to withstand extreme operating conditions, such as high temperatures, mechanical wear, and chemical corrosion. This ceramic material is highly resistant to abrasive and erosive wear, making it ideal for use in harsh industrial environments.

Another benefit of using wear-resistant ceramic pipelines is their superior thermal insulation properties. The material used in these pipes enables them to maintain a stable temperature, which is essential for the proper functioning of lithium battery cells. This stability helps to reduce the risk of temperature-related damage to the internal components of the battery, prolonging battery life.



Furthermore, wear-resistant ceramic pipes are highly resistant to chemical corrosion, making them an ideal choice for lithium battery cathode material pipelines. This is because the lithium battery cathode material tends to react with the environment, causing degradation and damage to the pipeline. However, the advanced materials used in wear-resistant ceramic pipes are highly resistant to chemical corrosion, which helps to protect the pipeline and prolong its useful life.



In addition to their durability, wear-resistant ceramic pipelines provide superior dimensional stability, which is essential for maintaining the accuracy and precision of lithium battery cell manufacturing. They also offer high resistance to abrasion, impact, and other forms of mechanical wear, which helps to maintain the integrity of the battery cell and prevent failure.



In conclusion, wear-resistant ceramic pipelines offer a range of benefits that, combined with their high durability and resistance to wear, corrosion, and temperature changes, make them an excellent choice for lithium battery cathode material pipelines. Their increasing popularity in recent years can be attributed to their unique benefits, which make them a more reliable and cost-effective option for lithium battery cell manufacturing.
