Home > products > Ceramic Sleeve Lined Pipe > Wear Resistance Ceramic Lined Pipe Fittings Custom Ceramic Lined Elbows

Wear Resistance Ceramic Lined Pipe Fittings Custom Ceramic Lined Elbows

Product Details

Place of Origin: Changsha, Hunan, China

Brand Name: Ibeno

Certification: ISO9001-2015

Model Number: Ceramic Sleeve Lined Pipe

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Packed in wooden cases or iron racks

Delivery Time: 25-45 workdas

Payment Terms: T/T

Supply Ability: 100,000 ㎡/ year

Get Best Price
Highlight:

Ceramic Lined Pipe Fittings Custom

,

Custom Ceramic Lined Elbows

,

Wear Resistance Ceramic Lined Pipe Fittings

Abrasion Resistance:
High
Advantages:
High Wear Resistance, Long Service Life
Color:
White
Corrosion Resistance:
Excellent
Customization:
Available Upon Request
Density:
3.65g/cm³
Inner Lining Material:
Alumina Ceramic
Installation Method:
Flange Connection
Lining Material:
Alumina Ceramic
Lining Thickness:
3-10mm
Material:
Ceramic
Size:
1 Inch - 24 Inch
Abrasion Resistance:
High
Advantages:
High Wear Resistance, Long Service Life
Color:
White
Corrosion Resistance:
Excellent
Customization:
Available Upon Request
Density:
3.65g/cm³
Inner Lining Material:
Alumina Ceramic
Installation Method:
Flange Connection
Lining Material:
Alumina Ceramic
Lining Thickness:
3-10mm
Material:
Ceramic
Size:
1 Inch - 24 Inch
Wear Resistance Ceramic Lined Pipe Fittings Custom Ceramic Lined Elbows

Product Description

The ceramic Lined Pipe and Fittings has overcome the low hardness and wear resistance of the steel pipe due to the high strength, good toughness, impact resistance, good welding performance of the steel pipe and the high hardness, high wear resistance, corrosion resistance, and heat resistance of the corundum porcelain. It has the characteristics of poor performance and poor ceramic toughness.



Ceramic lined Pipe and Fittings mainly include straight pipe, elbow, tee, reducer, etc. The lined ceramic process is divided into two types: ceramic patch and integral ceramic ring lining.



1. The wear-resistant lining ceramic is a patch process, and the alumina content is 95%, which is 10 times the service life of ordinary pipes. The equipment is dusted and polished, and the high-temperature and high-strength adhesives are used to paste and solidify the ceramic and equipment. The ceramic Lined Pipe and Fittings are widely used in electric power, metallurgy, mining, coal, chemical industry, lithium battery, construction machinery, port, and other industries.



2. The overall wear-resistant ceramic lined pipeline is made by using isostatic pressing technology to integrally fire the wear-resistant ceramic tube and pour it inside the steel pipe. Very strong. It is mainly suitable for material transportation of lithium battery materials, mineral powder, limestone, mineral processing, metallurgy, electric power, coal, and other industries.

Wear resistant engineering ceramicsceramic lined bendHigh density alumina ceramic

Ceramic technical parameters

Items Specifications
Content of alumina ≥92% ≥95%
Density ≥3.6 g/cm3 >3.8g/cm3
Rockwell A hardness ≥82HRA ≥85HRA
Impact strength ≥1200 MPA ≥1500 MPA
Fracture toughness ≥3.8MPa·m1/2 ≥4.0MPa·m1/2
Vickers hardness ≥1150HV10 ≥1200HV10
Bending Strength ≥290MPa ≥330MPa

Differential performance of ceramic lining bending tube and casting steel and cast steel

The fundamental reason for wear-resistant high-aluminum ceramic lining materials is the fundamental reason for excellent quality of the product itself, and the advantages of many aspects of the traditional material, such as cast stones, cast steel, and other materials.



1. Casting stones: The characteristics of wear-resistant cast stone elbow are fragile, cracking, and wear the noodle backpack, 25-35 mm wall thickness, and after a short time in the inside, the coal is worn outward with the gap and the service life is used to use the service life. It cannot be guaranteed that once it is worn, it cannot be repaired at the scene.



2. Casting steel: cast steel is widely used in the field of abrasion and anti-wear, and the manufacturing process is very simple. The surface hardness (about 60) of cast steel materials is much lower than ceramic (above 80), and the wear resistance is only one-tenth lower than the ceramics. In addition, cast steel pipelines are large, very bulky, and have high carbon content, and poor weldability. It is necessary to treat welded seams on the spot, which brings considerable difficulties to installation and maintenance.



Product testing

The company strictly controls each process of the production of ceramic lining elbows. We will have a series of testing equipment to conduct quality inspections to ensure that each product is 100% qualified.

Testing equipment Testing purpose
Rockwell hardness tester measuring the hardness of ceramics
Sandblasting testing machine measuring ceramic abrasion
Universal material testing machine measuring the compressive strength of ceramics
Microscope Porosity Analysis of Ceramic Surface
Universal material testing machine measuring the compressive strength of ceramics
Tensile testing machine Tensile testing
Density meter ceramic density analyzer
Impact testing machine ceramic compressive strength test

Packing and shipping

1. According to the product size, the company has special personnel to design and customize the packaging according to the drawings.

2. The packaging forms include fumigation-free wooden boxes and iron shelf packaging. The packaging method is selected according to the weight and structure of the product.

3. The outside of the product or wooden box will be packaged with bubble film or cling film, in order to prevent rust and not be wet by rain

4. The label will be affixed to the outside of the package.

5. The relevant inspection report or shipping list of the goods will be sent with the goods or sent to customers in electronic form.

Pipe lined with ceramicWear-resistant ceramic pipe packagingCeramic elbow
