Ceramic Lined Equipment Ceramic Wear Plates In Steel Industry

Product Details

Place of Origin: Changsha, Hunan, China

Brand Name: Ibeno

Certification: ISO9001-2015

Model Number: Ceramic Lined Equipment

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Packed in wooden cases or iron racks

Delivery Time: 25-45 workdas

Payment Terms: T/T

Supply Ability: 100,000 ㎡/ year

Get Best Price
Highlight:

Wear Resistance Ceramic Wear Plates

,

Ceramic Wear Plates In Steel Industry

,

Steel Industry Ceramic Wear Plates

Material:
Ceramic
Chemical Resistance:
Strong
Application:
Abrasive And Corrosive Environments
Corrosion Resistance:
Excellent
Wear Resistance:
High
Manufacturer:
Ibeno
Customizable:
Yes
Temperature Range:
Up To 400°C
Size:
Customizable
Maintenance:
Easy
Resistance:
High Temperature
Pressure Range:
Up To 10 Bar
Material:
Ceramic
Chemical Resistance:
Strong
Application:
Abrasive And Corrosive Environments
Corrosion Resistance:
Excellent
Wear Resistance:
High
Manufacturer:
Ibeno
Customizable:
Yes
Temperature Range:
Up To 400°C
Size:
Customizable
Maintenance:
Easy
Resistance:
High Temperature
Pressure Range:
Up To 10 Bar
Ceramic Lined Equipment Ceramic Wear Plates In Steel Industry

Product Description

The Ceramic Lined Equipment uses special super glue to paste the rubber composite wear-resistant ceramic lining plate inside the equipment or fix the wear-resistant ceramic lining plate of the ceramic rubber steel plate integrated vulcanization technology on the surface of the equipment with bolts to form a very strong wear-resistant layer. It mainly solves the problem of serious equipment wear when transporting bulk materials in thermal power, metallurgy, steel, mining, coal, cement, and other industries. Due to the use of rubber composite wear-resistant ceramic lining plates, it can effectively resist the impact of bulk materials. The product adopts a comprehensive structure of bonding steel parts and wear resistant ceramic lining plates, which is convenient for rapid replacement and construction.

ceramic tile liningceramic lined equipmentchute liner

Product parameters

Items Specifications
Content of alumina ≥92% ≥95%
Density ≥3.6 g/cm3 >3.8g/cm3
Rockwell A hardness ≥82HRA ≥85HRA
Impact strength ≥1200 MPA ≥1500 MPA
Fracture toughness ≥3.8MPa·m1/2 ≥4.0MPa·m1/2
Vickers hardness ≥1150HV10 ≥1200HV10
Bending Strength ≥290MPa ≥330MPa

Product use

Ceramic Lined Equipment is widely used in coal conveying systems of thermal power generation and material conveying and batching systems in metallurgy, iron and steel, cement, and other industries, such as coal drop hoppers, raw coal hoppers, receiving hoppers, drum rubber, fan impeller, dust removal pipe, Chutes, etc. The following are the more specific details:

Steel industry: coke hopper, hopper, ore transfer hopper;

Thermal power industry: coal drop bucket, vertical mill feed chute;

Cement industry: ore chute, crusher hopper, V selection feed chute;

Mineral processing industry: coke hopper, hopper, ore transfer hopper;

Coal mining industry: coal drop bucket;

Port industry: Botou fixed hopper, belt transfer station hopper, belt transfer station chute;

Chemical industry: coal drop hopper;

Applicable process: pulverizing, sintering, pelletizing, ironmaking, combustion, desulfurization, washing, coal conveying

Conveying method: pneumatic conveying, hydraulic conveying, material conveying

Applicable wear forms: erosion wear, abrasive wear, impact wear, adhesive wear, corrosion wear, surface fatigue wear

Applicable material form: fine powder (<1mm), coarse powder (<3mm), particulate matter (<5mm), bulk material (<10cm), bulk material (>10cm), slurry

Applicable temperature: -50-0℃, 0-100℃, 100-300℃, 300-500℃



FAQ

Q: Are you a trading company or a manufacturer?

A: We are a manufacturing enterprise specializing in the production of wear resistant ceramic pipes, wear resistant ceramic liners, and ceramic linings for various equipment.



Q: Do you provide samples? Is it free?

A: If the value of the sample is low, we will provide it for free, but the freight needs to be paid by the customer. But for some high-value samples, we need to charge a fee.



Q: Why choose us?

A: 1. Manufacturing experience: 15 years of industry experience, rich on-site practical experience, can provide the best and best anti-wear solution according to the customer's site

2. Installation and construction team: We have a construction team of 10 to 15 people, all with more than 10 years of construction experience

3. Quality assurance: All products have a strict quality inspection before shipment.

4. Price advantage: factory direct sales, competitive price.

5. Competitive production capacity and fast transportation.

6. Our company provides OEM service.



Q: Which industries are your products used in?

A: Our products are widely used in steel, thermal power, cement, ports, coal, mining, chemical, machinery, concrete engineering machinery, lithium batteries, and other industries.
