Product Details
Place of Origin: Changsha, Hunan, China
Brand Name: Ibeno
Certification: ISO9001-2015
Model Number: Alumina Ceramics
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Packed in wooden cases or iron racks
Delivery Time: 25-45 workdas
Payment Terms: T/T
Supply Ability: 100,000 ㎡/ year
Chemical Resistance: |
Excellent |
Color: |
White |
Compressive Strength: |
1200 MPa |
Density: |
3.5-3.6 G/cm3 |
Hardness: |
9 Mohs |
Rockwell Hardness: |
85 HRA |
Material: |
Al2O3 |
Vickers Hardness: |
900HV10 |
Other Name: |
Abrasion Resistant Ceramic |
Chemical Resistance: |
Excellent |
Color: |
White |
Compressive Strength: |
1200 MPa |
Density: |
3.5-3.6 G/cm3 |
Hardness: |
9 Mohs |
Rockwell Hardness: |
85 HRA |
Material: |
Al2O3 |
Vickers Hardness: |
900HV10 |
Other Name: |
Abrasion Resistant Ceramic |
Product Description
Alumina tiles are made of Al2O3 as the main raw material and metal oxides as the solvent. The corundum ceramics are sintered at a high temperature of more than one thousand degrees. The wear-resistant ceramic liner is very high in hardness and wear resistance. Under normal circumstances, the service life of alumina tile is as long as 10 years.
Product Features
In the pulverizing, ash, dust removal, and coal conveying systems of coal-fired power plants, the equipment is constantly affected by factors such as friction, corrosion, collision, and impact of the medium during the operation of the equipment, and the system is extremely prone to leaks and causes environmental pollution. For this reason, various power plants have adopted different leakage control methods accordingly. Among them, alumina ceramic wear tile is an ideal leakage control material, and its wear resistance, practicability, and economy are superior to other wear-resistant materials.
Alumina ceramic tiles are industrial wear-resistant, impact-resistant, and corrosion-resistant materials. Anti-vibration and thermal expansion and contraction: The thermal expansion coefficient of viscose is between steel and ceramics, which can well adjust the extrusion of ceramics due to the inconsistency of thermal expansion between ceramics and steel; at the same time, a variety of flexible fibers are added to the viscose, To ensure that the ceramics will not fall off for a long time under the environment of vibration and frequent thermal expansion and contraction.
High-alumina ceramic tile is a material transportation equipment for steel mills and power plants. It can also be used as a wear-resistant material for liquids flowing through the surface of the pipe. Its main function is to effectively resist the impact of the material on the pipe wall when the material passes, and chemical substances. The corrosive effect and the thermal shock effect of the material passing through time, greatly reduce the wear and tear caused to the internal parts of the equipment.
The installation of alumina tile mainly uses strong adhesive to stick the wear-resistant ceramics on the surface of the equipment's steel parts. The wear-resistant ceramics are installed by pasting, which can ensure long-term work without falling off, and can effectively protect the power plant equipment and extend the use time.
Alumina tile is a high-performance ceramic product that is widely used in a variety of industrial applications. Alumina is a ceramic material that is obtained from bauxite ore and contains upwards of 99% aluminum oxide. This high-purity aluminum oxide is what gives alumina its unique physical properties, including its high thermal resistance, high mechanical strength, and excellent wear resistance.
Alumina tile is a versatile product that can be designed, manufactured, and supplied in a wide range of sizes, shapes, and thicknesses. This means that it can be customized to meet the specific needs of different industrial applications. Some of the key features and benefits of Alumina Tile include:
1. Exceptional Wear Resistance
Alumina Tile has exceptional wear resistance, making it ideal for abrasive and demanding environments. It is resistant to erosion, corrosion, and chemical attack, which means that it can withstand harsh operating conditions and maintain its performance over time.
2. High Thermal Resistance
Alumina Tile has high thermal resistance, which means that it can withstand high temperatures without cracking or degrading. This makes it ideal for use in high-temperature environments, such as furnaces and kilns.
3. High Mechanical Strength
Alumina Tile has high mechanical strength, which means that it can withstand mechanical stresses and strains without breaking or deforming. This makes it ideal for use in applications where high loads and stresses are present.
4. Customizable Shape and Size
Alumina tiles can be designed, manufactured, and supplied in a wide range of sizes, shapes, and thicknesses. This means that it can be customized to meet the specific needs of different industrial applications.
5. Cost-effective
Alumina Tile is more cost-effective than other materials such as steel, as it has a longer lifespan and requires less maintenance.
Alumina Tile finds various applications across many industries, including:
1. Mining and Mineral Processing
Alumina Tile can be used in mining and mineral processing applications to protect equipment from abrasion and to minimize downtime.
2. Power Generation
Alumina Tile is used in power generation applications as it is resistant to high temperatures and can withstand thermal cycling, making it ideal for use in boilers, furnaces, and other high-temperature equipment.
3. Ceramic Manufacturing
Alumina Tile is also used in the manufacturing of other ceramic products like refractories, glass, and coatings.
4. Chemical Processing
Due to its chemical resistance, alumina tile can be used in the construction of chemical processing equipment.
5. Steel Industry
Alumina Tile can be used in the steel industry to line furnaces, ladles, and other equipment that is exposed to high temperatures and wear.
In conclusion, being a versatile, high-performance ceramic product, Alumina Tile is an excellent choice for any industrial application requiring wear resistance, and thermal, and mechanical strength. Not only is it customizable, but it also offers a longer lifespan and requires less maintenance than other materials, making it cost-effective. With applications in many industries, Alumina Tile is a reliable upgrade to equipment that will prolong its lifespan and withstand harsh operating conditions.
Product advantages
First of all: Compared with ordinary pipes, wear-resistant ceramic pipes are inherently corundum ceramics, so their life can be maximized during use, which is generally ten times or even dozens of times that of ordinary steel pipes. This is amazing. Many people will sigh after listening to the numbers. Then the cost of using this kind of pipeline will be very low? Of course, because it has a longer service life, it can be maximized in the economic cost that we are most concerned about. Saved.
Secondly: because it is inherently ceramic, it has the property of not being afraid of high temperatures, which determines that it can have a certain degree of thermal stability during use, so there is no too much picky about the working environment and the nature of the work. .
Finally: this kind of wear-resistant ceramic pipe has another advantage in its welding place. Compared with ordinary steel pipes, this kind of pipe can be stronger in welding, so it can be used for a longer period of time, let alone worry about it. There are problems in the process of use, because of the various advantages of wear-resistant ceramic pipes, Many factories and companies will favor this product more, and after we use this pipe, the cost of the project cost is also The greatest savings can be achieved.
Why choose us?
1. Our Alumina Ceramic Liner products are backed by a comprehensive warranty to ensure customer satisfaction.
2. To our customers, we will provide a strong impetus for economic development through our quality Alumina Tile and services.
3. Our Alumina Ceramic Liner products are built to withstand even the toughest environments and applications.
4. We are adhering to the development concept of 'integrity and dedication, close to users, and professional technology', and serve customers with strong technical force, complete testing equipment, stable and reliable product quality, and thoughtful after-sales service.
5. Our Alumina Ceramic Liner products are made using the latest manufacturing techniques and equipment.
6. We will pay more attention to innovation and change, and more emphasis on learning and improvement.
7. Our commitment to quality is evident in every Alumina Ceramic Liner product we produce.
8. Our company has already set up an experienced, creative, and responsible team to develop clients with the multi-win principle.
9. We provide timely and efficient delivery services for our Alumina Ceramic Liner products worldwide.
10. We are committed to exploring new service models, becoming a new representative of the Alumina Tile industry, and forming our own unique services.
